Model NO.	W-7
Principle	Neutral-type Filter
Material	Glass
Shape	Customized
Certification	RoHS, ISO, CE, TUV
Customized	Customized
Glass Quality ND	±0.0001
Coating	Coating:Ar or Bbar
Scratch/Dig	20/10
Parallelism (Arc Min)	<1 S
Dimension Tolerance	0.01/-0.01
Clear Aperture	100%
Delivery	DHL/UPS/TNT/EMS/FedEx
Glass Quality Vd	±0.1%
Processing	Slicing,Grinding,Polishing,Single Point Turning .
Transport Package	Air Cushion Wrappaed Carton Packaging.
Trademark	Oplens
Origin	Chengdu, Sichuan, China
HS Code	9001909090
Production Capacity	200000PCS/Month

Product Description

Product Description K9 High-precision Wedge Window (uncundered, VIS Film, NIR Film, SWIR Film) Optical Components Optical Windows are flat, optically transparent plates that are typically designed to maximize transmission in a specified wavelength range, while minimizing reflection and absorption. They are often used to protect optical systems and electronic sensors from an outside environment. Because windows introduce no optical power into a system, windows should be selected based on the material transmission properties, optical surface specifications, and the mechanical properties that match your application.

Material Properties

Material properties including the transmission, refractive index, and hardness of the window substrate can be critical for deciding which window is the best choice for your application. The figure below highlights the transmission regions of the different materials Oplens® offers as windows.

Product parameters
Material		BK7 and Fused silica typically, Visible optical glass,Infrared optical glass, Colored glass.
Tolerances		Low precision	Standard precision	High precision
Glass Quality	nd	±0.001	±0.0005	±0.0001
	vd	±0.8%	±0.3%	±0.1%
Dimension Tolerance(mm)		±0.20	±0.10	0.01/-0.01
Thickness Tolerance(mm)		±0.20	±0.1	±0.005
Scratch-Dig		V(80-50)	IV(60-40)	II(20-10)
Wave front Distortion 632.8nm		λ per 25mm	λ /4per 25mm	λ /20 per 25mm
Clear Aperture		80%	90%	100%
Parallelism (arc min)		3-5 minutes	1 minutes	<1 second
Bevel		0.3±0.20mm×45° or upon requirement
Coating		Coating may be available by custom order
